Purchase code (product model)

AS-6771

Performance parameters

CPU

MT6771, 8-core ARM® Cortex-A73 MPCoreTM, clocked at 2.0GHz

operating system

Android 11

RAM/ROM

EMCP:6GB+128GB/4GB+64GB

language

multi language

Display parameters

size

10.1 inches

Resolution

1920*1200

brightness

Minimum

Typical Value

Maximum

360nit

450nit

500nit

Perspective

Full Viewing Angle IPS

Area A

135.36(H)*216.576(V)

Touch parameters

Touch screen type

Capacitive touch panel

Touch method

Support 10-point touch G+G

Light transmittance

More than 90%

Camera

Front camera 5.0M + rear camera 13.0M (with flash)

GPS

Support Beidou+GPS+glonass; capture sensitivity: -163 dBm

NFC

ISO/IEC14443, ISO/IEC15693, MIFARE, Felica, card reading distance: 3-5cm, front

trumpet

8Ω, 1.5Wx1

MIC

Sensitivity: -32±2d, output impedance 2.2kΩx1

TF card

Expandable external storage x1

button

Power, V+, V-, P, F, H

Machine weight

980g

Product size

275*178*18mm

Data Communication

WIFI

802.11a/b/g/n/ac, Wireless AP (Mobile AP)2.4G, 5G

Bluetooth

BT4.2, backward compatible

Network Standard

TDD-LTE: B34/B38/B39/B40/B41/B66

FDD-LTE: B1/B2/B3/B4/B5/B7/B8/B12/B17/B20/B28

WCDMA: B1/B2/B4/B5/B8

CDMA2000: BC0

TD-SCDMA: B34/B39

GSM: B2/B3/B5/B8

interface

Type-A

USB2.0 x1

Type-C

Download/Charge x1

RJ45 Ethernet

10/100M x1

3.5mm headphone jack

∮3.5mm standard headphone jack x1

DB9 RS232

9-pin serial port x1

DC power interface

DC 5V 3A ∮3.5mm power interface x1

sensor

Light Sensitivity

support

distance

support

Earth's magnetism

support

Gyroscope

support

Accelerometer

support

Air pressure sensor

support

Pogopin

Back 16PIN

USB2.0x1+UART RS232x1

Bottom 8PIN

USB2.0x1+UART RS232x1x1+charging

multimedia

Image Preview

BMP, JPG, GIF, PNG

Video Format

MEPG 1/2/4,H.263/H.264,RMVB,WMV/VC-1,MVC,AVS,MJPEG. (UP TO 1080P)

Audio Format

MP3,WMA,WAV,OGG,FLAC,ALAC,APE,AAC,AC-3,DTS (need license)

Product reliability

Protection level

Waterproof IP65, designed for IP67

Falling 1.2 meters, 6 faces

Certification Standards

Military 810G

EU CE, US FCC

Operating temperature

-20℃～60℃

Storage temperature

-25℃～80℃

Battery Performance

Battery Type

Built-in removable polymer lithium-ion battery

Battery capacity

10800mAh, (optional: 12000mAh + 2400mAh)

Battery life

Video playback time

About 15 hours (70% volume, 70% lumen brightness, playing 1080 HD video)

Screen off standby time

About 200H

Optional

Fingerprint module

AFM60

Fingerprint capacity

500 pieces as standard

Identify time

<0.45 seconds

Identification method

1:N identification or 1:1 verification

2D code scanning module

N3680

Code reading

PDF417, MicroPDF417, Data Matrix, Data Matrix Inverse

Maxicode,QR Code, MicroQR, QR Inverse,Aztec,Aztec Inverses,Han Xin,Han Xin Inverse

High-precision GPS

ZED-F9P

Centimeter-level, supports Beidou, GPS, GLONASS, Galileo

UHF RFID

Built-in (European standard/American standard)

Output power range: 18-26 dBm; receiving sensitivity < -70dBm; card reading distance: 2-3 meters

External (European standard/American standard)

Output power range: 18-26 dBm; receiving sensitivity < -70dBm; card reading distance: 4-5 meters
