Model: AI-Q610
RFID industrial reader small all-in-one machine AI-Q610
$150.00
暂无数据
Chip:
Interface:
Protocol:
Frequency:
Shipping cost within 10kg is $100, and for every additional 1kg, the shipping cost increases by $5
Description
01. Physical advantages: IP67 protection level, can be used in various harsh environments;
02. Electrical performance advantages: small size, high gain, wide application scenarios;
03. Applicable scenarios: suitable for 902-928MHz frequency band passive integrated reader/writer system; can be easily applied to Modbus industrial production lines, access control, logistics management and other UHF frequency band RFID occasions.
Detail
|
Model No. |
AI-IRQ610 |
|
Performance |
|
|
Readable and writable tags |
Comply with ISO18000-6C Standard electronic tag |
|
working frequency |
865~868MHz ( European frequency EU) 902 ～ 928MHz ( US ) 920~925MHz ( China frequency CHN ) |
|
Working mode |
orks in broad spectrum frequency hopping (FHSS) or fixed frequency transmission mode; |
|
Output power |
13 ~ 27dBm ( may vary slightly depending on country or region ) |
|
Reading and writing distance |
The maximum card reading distance is 200cm , the maximum card writing distance is 200cm (AZ-9662 white card label ) |
|
Relay |
maximum contact load DC30V/2A , AC125V/0.5A |
|
Trigger |
The default is low level trigger (low level trigger reference voltage 0-2V , note: the signal line level of the access point must not exceed 12V ) |
|
Card reading speed |
average reading time per word (32bits) 6ms |
|
Card writing speed |
average writing time per word (32bits) 50ms |
|
powered by |
Standard DC12V/3A Power adapter, supports DC9V~DC24V Wide voltage input |
|
Power consumption |
maximum power consumption 30W , maximum starting current 2.5A |
|
Working environment temperature |
-40 ℃ ~ +85 ℃ |
|
Working environment humidity |
5%-95% Non-condensing |
|
communication |
RJ45、RS485、RS232 |
|
transmission rate |
Support 10M/100M |
|
size |
94*90*40mm |
