Model: AI-82A
AI-82A UHF RFID Forklift Reader
$550.00
暂无数据
Chip:
Interface:
Protocol:
Frequency:
Shipping cost within 10kg is $100, and for every additional 1kg, the shipping cost increases by $5
Description
1.Its shape adopts industrial design, rugged, which is in line with the harsh industrial environment (electromagnetic interference, dust, tamper-proof, resistant to the highest -40 ° - 85 ° environment, vibration) Shock standard: Vibration EN 60 068-2-6; Lightning standard: Shock EN 60 068-2-27; Magnetic compatibility (EMC): EN 61000-6-3 ( 2007)+A1(2011)/EN 61000-6-2(2005);
2.It supports electronic tags complying with EPCglobal UHF Class 1 Gen 2 / ISO 18000-6C/ ISO 18000-6B standards;
3.It supports WiFi, Bluetooth and other wireless communications;
4.It has a built-in 11800MAh rechargeable battery to ensure continuous life;
5.Its working frequency is 865~868MHZ, 902~928MHZ (can be adjusted according to the requirements of different countries or regions).
Detail
|
Product Model |
AI-82A |
|
Performance specification |
|
|
RF core chip |
IBAT2000 |
|
Air Port Protocol |
EPC Global UHF class1 Gen2/ISO 18000-6C/ISO 18000-6B |
|
Frequency Range |
902~928MHz or 865~868MHz |
|
RF Output Power |
0~33dBm±1dBm |
|
Maximum receive sensitivity |
-75 dbm; Maximum return loss:10 dbm |
|
Read distance |
200~5000mm（related to reader configuration, antenna gain, tag type） |
|
Write distance |
100~1000mm（related to reader configuration, antenna gain, tag type） |
|
Supported Regions |
The United States, Canada and other regions in accordance with the U.S. FCC Part 15 specification Europe and other regions compliant with ETSI EN 302 308 specifications China, India, Japan, Korea, Malaysia, Taiwan |
|
FM mode |
Broad spectrum FM (FHSS) or fixed frequency, software programmable |
|
Number of antennas |
Built-in 5dbi four-wall spiral antenna |
|
Reading landmark antenna (optional) |
1 SAM port |
|
Communication interface |
RS232、RS485、RJ45 |
|
Protocol support |
Normal version supports Modbus RTU, Modbus TCP protocols |
|
WiFi |
support IEEE 802.11 n/b/g |
|
Heating device (optional)
|
low-temperature automatic heating (-5 °) optional (according to the project site environment to determine) |
|
Communication rate |
Serial communication rate 9600 ~ 115200bps, RJ45 communication rate 10/100Mbps |
|
Working status display mode |
LED indicator, buzzer |
|
Trigger device |
Diffuse switch 1 meter distance |
|
GPIO |
2 inputs, 4 outputs |
|
Firmware upgrade |
Expandable upgrade mechanism or WIFI upgrade |
|
Application software interface |
API development kit and C and Java application routines are provided. |
|
Mechanical and Electrical Performance |
|
|
Dimension |
200(L)*200(W)*83.5(H)mm |
|
Built-in battery (capacity) |
11800mAH |
|
Charger |
12.6V 3A |
|
Power Consumption |
Maximum Power Consumption 3W, Maximum Startup Current 1A |
|
Weight after packing |
2kg |
|
Humidity |
5% ~ 95%, non-condensing |
|
Protection class |
IEC IP54 |
|
Operating Temperature |
-40°C ~ 80°C |
|
Storage Temperature |
-40°C ~ 85°C |
|
Connector Type |
Round waterproof M12 pin female chassis connector |
|
Mounting bracket type |
Fixing of aluminum profiles |
