Model: AT-H50
RFID high temperature resistant metal tag specification AT-H50
$2.20
暂无数据
Protocol:
Shipping cost within 10kg is $100, and for every additional 1kg, the shipping cost increases by $5
Description
1. This product is widely used in fine chemical industry production line management, with high sensitivity and strong anti-interference ability;
2. 100% passed the memory writing test;
3. The material and design have been tested for reliability.
Detail
|
Performance |
|
|
Product number |
AT-H50 |
|
working frequency |
1 3.56Mhz |
|
air protocol |
ISO -15693 |
|
read and write time |
0.01ms _ |
|
chip type |
NXP ICODE X , NXP ICODE X2 , MB89118C1-DIAP15-P1 24PF |
|
read and write performance |
Readable and writable (customers can repeatedly write content into the chip) |
|
storage |
112bits/256bits/2k bytes |
|
Erase life |
100,000 times /100,000 times /1 billion times |
|
physical parameters |
|
|
Sensing distance |
2-20cm |
|
Main material |
PPS |
|
surface color |
black |
|
Product Size |
50 mm*33mm aperture 5mm |
