Model No.

AC-420T

Performance Index

Frequency range

902-928MHZ/865-868MHZ(Can be adjusted according to different countries or regions)

FM mode

FHSS or fixed frequency, set by the software

RF output

20-30dBm adjustable

Antenna connection quantity

4 SMA antenna ports, 6dbi circular polarization or narrow beam antenna optional;

the height of antenna adjustable

Communication interface

LAN, RS232, RS485, Wiegand26/34, or wireless transmission

Communication rate

Serial port 9600～115200bps，RJ45 10Mbps

Power dissipation

average<25W

EAS Alarm

3s sound and light prompt

Infrared sensor

Judge in and out

GPI/O interface

12 pin + 4 pin

Reliable firmware upgrade

Extensible upgrade mechanism

Application software interface

Provide with API SDK and VC, VB, Java application routines

Tag Operation Performance

Channel width

Reading distance 1.5-3 meters (Tag dependent)

Air interface

EPC global UHF ISO-18000-6C（EPC G2), ISO18000-6B, TK900

Extended function (optional)

Android operating system

HD 10-inch Android touch screen, Android system 7.1 or above（VC-420TP）

Fast  intelligent temperature screening system

Face detection, blackbody face real-time temperature calibration

Mechanical and Electrical Performance

Dimension

157(L)x44.5 (W)x13(H)cm；Base 68 (L) x26 (W) cm

Power supply

220V AC input

Weight

36KG

Humidity

5% to 95%, non-condensing

Protection grade

IEC IP51(A rainproof shed is required for outdoor use)

Package

The outer packaging of the kraft board paper and built-in shock absorption that use  thickened version of pearl cotton to effectively reduce the damage caused by the external impact force.

Operation temperature

-20 ºC to 60  ºC

Storage temperature

-40°C to 80°C
