Purchase code (product model)

AH-C77

Physical parameters

Machine size

164.2X78.8X17.5mm

Machine weight

＜321g (depending on module configuration)

Display

5.2 inches, IPS LTPS 1920X1080 resolution

Touch screen

Corning Gorilla Glass, supports multi-touch, supports gloves or wet hands operation

Battery capacity

Rechargeable lithium polymer battery 5000 mAh

Standby time>350 hours

Working time>12 hours (depending on usage and network environment)

Charging time 3-4 hours (using the standard power adapter and data cable

Extension plug-in

2 slots, 1 Nano SIM card slot, the other one Nano SLM or TF card slot

Communication interface

USB 2.0 Type-C, OTG, support Type-C headset

Audio

2 microphones, 1 for noise cancellation, on the back; 1 speaker; earpiece

keyboard

4 main keyboard keys, 1 power key, 2 scanner keys, 1 multi-function key

sensor

Light sensor, distance sensor, gravity sensor

notify

Sound, LED indicator, vibration

Performance parameters

CPU

Octa-core 2.3GHz

RAM-ROM

3GB+32GB/4GB+64GB/6GB+128GB

Expanded Memory

MicroSD (TF) card can be expanded up to 256GB

Development Environment

operating system

Android 11/13

SDK

Terminal Software Development Kit

Developing Voice

Java

Development Tools

Eclipse / Android Studio

Usage Environment

Operating temperature

-20°C to 50°C

Storage environment

-40°C to 70°C

Ambient humidity

5%RH-95%RH(no condensation)

Drop test

Within the operating temperature range, all six sides can withstand multiple drops from a height of 1.8 meters to the concrete floor

Rolling test

Rolling continuously for 1000 times 0.5 meters, 6 contact surfaces still run stably after rolling, meeting IEC rolling specifications

Protection level

IP67, meets IEC sealing standards

Electrostatic Discharge

±15KV air discharge, ±6KV contact discharge

NFC (optional)

Operating frequency

13.56MHz

Protocol Standards

ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc.

Labeling standards

M1 card (S50, S70), CPU card, NFC tag, etc.

Reading and writing distance

2-4cm

Camera

Rear camera

13-megapixel color camera with auto focus and flash

Front camera (optional)

5-megapixel color camera

Data Communication

WLAN

Support IEEE802.11 a/b/g/n/ac protocol (2.4G/5G dual-band); built-in antenna

WWAN

2G:GSM850/GSM900/DCS1800/PCS1900

3G:WCDMA: B1/B2/B4/B5/B8

CDMA2000 EVDO: BCO

TD-SCDMA:A/F

4G:B1/B2/B3/B4/B5/B7/B8/B12/B17/B20/B28AB28B/B34/B38/B39/B40/B41

Bluetooth

Bluetooth 5.0

GNSS

Integrated GPS, Beidou, GLONASS, built-in antenna, support AGPS

RFID UHF (optional)

engine

Based on lmpinj E310 chip

China Frequency

920-925MHz

US Frequency

902-928MHz

European Frequency

865-868MHZ (ETSI EN 302 208)

Other frequencies

Other multinational frequency standards (customizable)

Impinj Gen2X

support

Protocol Standards

EPC C1 GEN2/ISO18000-6C

Antenna parameters

Circular polarization antenna (1.5dBi)

power

1 W (support +5dBm~+30dBm adjustment)

Max card reading distance

3m (lmpinj MR6 tag, size 70 x15mm)

3m (lmpinj M750 tag, size 70 x15mm)

4m (Alien H3 anti-metal tag, size 130 x42mm)

Note

*The above card reading distance is measured in an open outdoor low-interference environment, and the group reading rate is measured in a laboratory low-interference environment. The actual use is related to the environment and tags.

Barcode collection

1D Scan Engine

Honeywell N4313

2D Scanning Engine

Zebra:SE4710/SE4750SR/SE4750MR/SE4750DP;Honeywell: N6603;CM60: CB300

Support one-dimensional barcode types

UPC/EAN, Code128,Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar MSI.RSS, etc.)

Support 2D barcode types

PDF417, MicroPDF417, Composite, RSS, TLC-39, Data matrix, QR code, Micro QR code, Aztec, Maxi Code; Postal Codes: US Post Net, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KlX), etc.

Note

*This function is optional
