Model: APR-243D
300dpi RFID Printer APR-243D
$2053.00
暂无数据
Shipping cost within 10kg is $100, and for every additional 1kg, the shipping cost increases by $5
Description
The product adopts all-metal frame structure, sturdy and durable. Unique design of minimised internal mechanism parts, with hard appearance, it reduces the printer volume and looks more beautiful and generous under the premise of meeting all printer functions. The large transparent window design makes it easy to observe the status of the consumables; the side-opening ribbon and paper loading method, and the support of the bottom paper can be recycled, which is more space-saving.
The product is widely used in manufacturing, retail logistics, medical hospitals, government departments and other industries. The PX240SRH series is available in 3.5" full-touch colour display, 2.36" keyed small display and UHF RFID printers.
The product is widely used in manufacturing, retail logistics, medical hospitals, government departments and other industries. The PX240SRH series is available in 3.5" full-touch colour display, 2.36" keyed small display and UHF RFID printers.
Detail
|
Procurement code (product model) |
APR-243D |
|
Performance Parameters |
|
|
Working Temperature |
+5°C~+40°C(+41°F~+104°F) |
|
Storage Temperature |
-20°C~+70°C(-4°F~+158°F) |
|
Humidity |
20%~85%，without condensation |
|
Barcode Symbology |
Supports all major 1D and 2D symbols |
|
Supported Standards |
UPC/EAN Shipping Container、UCC/EAN128、Serial Shipping Container、MH10.8Shipping tag、AlAG (shipping partstag、OGMARS、POSTNET、HIBCC、ISBT128、GM1724、UPS Shippingtag and GlobalTransport tag |
|
Fonts |
Monotype font engine; can support non-Latin fonts through WTLE, customers can also download their own (Truetype) fonts |
|
Graphics |
PCX, PNG, GIF and BMP file formats are supported. Other formats are supported through tag Generation Tools. |
|
Printer Command Language |
Fingerprint (FP), Direct Protocol (DP).IPL, ZSim2 (ZPL-I), DPL; XML enabled for SAP® Al and Oracle® WMS. |
|
Application/Driver |
InterDriverWindows® Printer Driver and One-Click Driver Installation |
|
SMART PRINTING Print Language |
C# for Printers: Smart PrintingDeveloper Resource Kit; Read/Write Programmes using a NET-compatible Development Environment |
|
Configuration and Device Management Support |
Printset supports Windows for configuring printers; proven web interface for configuration, one-to-one management |
|
Power Supply |
PFC power supply rated at 100W AC voltage: 100V AC to 240V AC, 50Hz to 60Hz |
|
Certification Information |
This product is fully compliant with China CCC, CE, SRRC, EnergyStar, China and EU RoHS regulations. Please contact your local sales representative for more compliance information. |
|
Media Specifications |
Non-continuous tag stock, black tag stock, tag stock, perforated guide stock, notched stock or continuous tag stock Maximum/Minimum Width (tag and Liner) 114/20 mm (4.5/0.79 in)Minimum tag Length. Tear-off mode: 5.0 mm (0.197 in) Self-peel mode: 12.7 mm (0.5 in) |
|
Thickness (tag and Liner) |
3 mil to 10 mil |
|
Configuration |
Outer rolled roll or folded paper |
|
tag Roll Maximum Diameter |
203.2 mm (8.0 inches) |
|
tag Roll Cores |
76 mm (3.0 inches)/25.4 mm (1.0 inches) |
|
Interface Standard |
USB2.0 Host Interface |
|
Serial Protocol Supported |
USB2.0 device interface |
|
Printing Method |
Ethernet interface with 10/100 Mbps RS-232, transfer rate up to 115.2KB/S |
|
Processor |
Fingerprint/Direct Protocol: XON/XOFF, ENQACK, RTS/CTS |
|
Printing Resolution |
IPL: XON/XOFF, Honeywell Std. Protocol |
|
Print Speed |
Thermal transfer and thermal printing |
|
Maximum Print Width |
Arm Cortex®-A7,800MHz128 MB Flash 128 MB DDR3 SDRAMMulti-GB USB storage (FAT16/FAT32) |
|
Maximum Continuous Print Length |
Built-in real-time clock |
|
Length x Height x Width |
203 dpi:8 dots/mm300 dpi:11.8 dots/mm |
|
Maximum Continuous Print Length |
203 dpi:50-250 mm/s (2-10 ips)300 dpi:50-200 mm/s (2-8 ips) |
|
Ribbon Support |
At 203 dpi:108 mm (4.25 inches)At 300 dpi:105.7 mm (4.16 inches) |
|
Maximum Ribbon Core Diameter |
203 dpi: 4.8 m (15.75 ft) 300 dpi: 2.2 m (7.22 ft) |
|
Ribbon Core I.D. |
L:438 mm H: 270 mm W: 249 mm(17.24 in x 10.63 in x 9.80 in) |
|
Maximum/Minimum Ribbon Width (Ribbon and Core) |
10.82 kg(23.85 lbs) |
|
Ribbon Type |
Internal or External Carbon |
|
RFID specification (optional, factory-installed) |
|
|
Standards |
ISO 18000-6C |
|
Protocols |
EPC GEN2 PROTOCOL |
|
Frequency Bands |
920~925MHZ |
|
RFID Characteristics |
Integrated UHF RFID reader/encoder module; mark damaged or unreadable invalid RFID tags; RFID intelligent calibration technology will match the best print performance corresponding to the RFID parameters; support for user-defined Inlay position, rapid calibration of the readable area; support for simultaneous printing, encoding. |
|
RFID Tag Type |
Support minimum label height 12.5mm Support minimum Pitch 16mm RFID tag thickness up to 1.5mm Supports flexible metal-resistant tags |
|
Gen2 Storage |
Extended EPC, User Memory, TID, Access Code, Lockout |
|
Print Resolution |
Optional 203DPI and 300DPISKU |
